Precision Tubes, Metal Strip, Foil & Clad Plate products for Nuclear Applications

Nuclear

We have more than 75 years’ experience supporting the nuclear industry. Our high-performance nuclear products are quality-assured and used in critical power plant applications worldwide - where precision, integrity and 100% reliability are paramount.
Products
  • High-quality, precision tubes
  • Precision metal strip
  • Roll bonded clad plate

  • High Quality Tubes +


    We are a leading supplier of specialty alloy tubing to the nuclear sectors. Our high-quality tubes are engineered for extreme heat, pressure and corrosion resistance for safety-critical nuclear applications. We are NADCAP, RCC-M accredited, based on ASME III requirements.p>

    Alloys

    • Titanium (Ti CP (Grade2)
    • Zirconium (Zircaloy-2, Zircaloy-4)
    • Nickel (200, 201, 211 Monel® 400, 600, 625, 690, 718, 800, 825)
    • Stainless steel (303Se, 304/304L, 316/316L, 316LVM, 321, 347)
    • Duplex steels (Duplex S31803, Superduplex S32750, Superduplex S32760)

    Sizes
    Our tubing sizes typical for nuclear power applications range from 2.4mm (0.095”) to 45mm (1.77”) OD in seamless, welded & redrawn. Other sizes are available on request, starting from 0.15mm (0.006”) OD.

    Applications

    • Primary and field instrumentation
    • Control Rods/RCCA’s
    • Fuel cans
    • Cladding tubes
    • Flux thimble guide tubes
    • Grid sleeves
    • Seamless nickel coils for flux detectors
    • Other fuel assembly components


  • Precision Metal Strip +


    Custom-re-rolled metal strip manufactured in high performance alloys. Engineered with non-standard thicknesses and widths, custom surface finishes and mechanical properties to precisely match your specifications.

    Alloys
    Stainless steel strip and zirconium strip.

    Applications

    • Stainless steel for use in a Candu reactor as braising foil in the fuel bundle assembly.
    • Zirconium strip for use in a PWR reactor as a strap in a fuel assembly.


  • Roll Bonded Clad Plate +


    Our proven roll bonded technology is used to engineer clad metal plate for nuclear applications. The clad plate combines the properties of dissimilar metals to produce a material superior to any of the individual metals taken alone.

    Alloys
    Stainless steel and Nickel based roll bonded clad plate.

    Sizes

    Thickness up to 1” and width up to 96”.


Downloads
Nuclear Tube Brochure
Strip Brochure
Clad Plate Brochure
