Electronics

Our precision nickel strip is manufactured via wrought powder metallurgy for 99.98% purity. The material delivers 15-20% higher conductivity than traditional cast nickel strip for battery connectors.

The high conductivity of our nickel products makes it the choice for demanding electronic applications.

Alloys
Ni200, Ni 201, Ni270, 899L and 899A.

Sizes
Thickness down to 50 microns, standard and custom sizes and tempers available.

Applications
Battery tab connectors.

Our Molybdenum-Copper and Tungsten-Copper composites are custom-engineered for management of heat in electronics packages.

Our products are used as both the hermetic housings and as expansion-matched heat sinks and thermal spreaders for electronics.

Due to their excellent thermal conductivity and controlled thermal expansion, our products are the preferred materials for Gallium Arsenide (GaAs) and Gallium Nitride (GaN) semiconductors for the electronics and defense industry.

Alloys
Molybdenum-Copper (AMC) and Tungsten-Copper (AWC) composites

• Width: 4 inches (102 mm).
• Thickness: 3 inches (76 mm)
• Length: 24 inches (610 mm)

Applications
Electronic packages, high power semiconductors, microwave packages, high RF applications, laser mounts, optoelectronics, advanced active radars, electronic countermeasures, and jamming equipment.

We offer strip and wire products in alloy C72900 (Pfinodal®) for manufacturing of connectors in the electronics industry.

A major benefit of the material is the lack of stress relaxation during heat treatment following forming of parts. As compared to beryllium copper alloys, the C72900 materials maintain tolerance much better when undergoing the final heat treatment step.

Parts operating in harsh environments maintain their shape at higher temperatures ensuring that electronic contact is maintained and minimizing unplanned downtime for equipment.

Alloys
C72900 (Pfinodal®).

Applications
Electronic connectors.

Re-rolled flat and specialty shaped wire in a wide range of alloys and sizes. Our sophisticated forming technologies and engineering expertise enable us to work to the tightest tolerances.

• High purity wrought powder metallurgy alloys include nickel, Pfinodal®, and nickel Irons.
• Other materials: copper and copper alloys, nickel alloys, stainless steel, carbon steel, aluminum and any commercially available custom alloys.

• Square 0.010” (0.254 mm) to 0.200” (5.08 mm)
• Round 0.004” (0.101 mm) to 0.250” (6.35 mm)
• Flat 0.008” (0.203 mm) to 0.018” (0.457 mm)

Applications
Wire for lids and leads, braid wire for braided cables.

We are experts in manufacturing precision resistor alloy foil used for strain gauges. Foil strain gauges are used as the active element in the production of electronic load cells, for structural stress analysis and other load or force-sensing applications.

Alloys
Constantan, Evanohm® R and Nickel 270 (N02270)

Sizes
Thickness down to 0.0025mm and up to 101mm wide, custom sizes available on request.

Applications
Strain gauges.

Our precision alloys are used by flexible foil heater manufacturers around the world. They rely on Hamilton Precision Metals for the critical chemistry, mechanical properties, and tolerancing required for their heater products.

Alloys
HPM® 600 N06600, HPM® 965, Cu-Ni 715 UNS C71500, Evanohm® R, HPM® 80/20A and Commercially Pure Nickel

Sizes
Precision strip manufactured from 1.5mm (0.060”) down to 1.5 microns (0.000060”) in thickness.

Applications
The heaters are used in a variety of applications such as telecommunication switching equipment, medical diagnostic devices, and aircraft components to guard against cold at high altitudes.

Hamilton Precision Metals is a leading supplier of thin titanium strip used in the production of high-end speaker diaphragms. The titanium material is drawn into a dome and operates in high performance speaker applications including concert speakers and premium home and automotive stereo systems.

Alloys
Titanium CP Grade 1 and Titanium CP Grade 2

Sizes
Precision strip manufactured from 1.50mm down to 1.5 microns (0.000060”) in thickness.

Applications
Speaker domes.
